The Full Grip - Clamping Studs for Individual Adaptation, 16 mm

The Full Grip – Clamping Studs for Individual Adaptation, 16 mm

Versatile Zero-Point Studs Designed for Custom Fixtures and Special Applications

When off-the-shelf just doesn’t cut it, The Full Grip – Clamping Studs for Individual Adaptation give you the freedom to build your own custom fixtures without sacrificing zero-point accuracy. Engineered for seamless integration into both 52 mm and 96 mm clamping systems, these studs are perfect for toolmakers, R&D departments, or anyone who needs precision without being locked into standard configurations.

Each stud is manufactured to exacting tolerances using hardened tool steel, ensuring rock-solid clamping, high load capacity, and repeatability you can rely on — even under demanding machining conditions.

Key Features:

• Adaptable Design:
  Supplied without a fixed mounting body so you can integrate them into custom plates, fixtures, or special-purpose components.

• Zero-Point Compatibility:
  Available in both 52 mm and 96 mm system formats, fully compatible with The Full Grip base plates and most major zero-point systems on the market.

• Extreme Precision:
  Machined for tight repeatability (≤ 0.005 mm) — ideal for critical positioning in CNC machining and metrology setups.

• Hardened for Longevity:
  Made from high-strength tool steel and hardened to resist wear, deformation, and corrosion in industrial environments.

• Secure Locking:
  Designed for positive mechanical engagement with pull-back and locking mechanisms in zero-point bases.

• DIY Friendly:
  Perfect for fixture builders and engineers looking to integrate zero-point technology into their own designs.

Technical Specifications:

• System Types: 52 mm or 96 mm

• Material: Hardened tool steel (min. 56 HRC)

• Mounting: Raw-body format for custom installation

• Repeatability: ≤ 0.005 mm

• Compatible With: The Full Grip zero-point plates and most 3rd-party systems using 52/96 mm spacing

• Use Case: Custom fixture plates, modular jigs, special workholding applications

DIMENSIONS:

Ø 16 mm

for 52 mm spacing,
incl. M 8 × 1.25 threaded pin
