The Full Grip - Mini Dovetail Clamp - 52 stud 97D*84mm

The Full Grip – Mini Dovetail Clamp

52 Stud | 97D × 84 mm
Compact Workholding for High-Precision 3- and 5-Axis Machining

Designed for high-performance workholding in limited spaces, the Full Grip – Mini Dovetail Clamp delivers maximum rigidity with a minimal footprint. With its integrated 52 mm zero-point stud and precision-machined dovetail form, this compact clamp is ideal for small part machining, especially in 5-axis applications where accessibility, clearance, and accuracy are critical.

Its 97 mm diameter and 84 mm height make it compact enough for tight setups, while the built-in 52 mm stud provides seamless compatibility with The Full Grip zero-point base plates and all standard 52 mm clamping systems.

Key Features:

• Mini Form Factor:
  At just 97 mm in diameter and 84 mm tall, this clamp is ideal for smaller parts, tight toolpaths, and compact machine setups.

• Integrated 52 mm Stud:
  Built-in pull-stud ensures fast, repeatable changeovers with all standard 52 mm zero-point bases.

• Dovetail Holding Strength:
  Provides strong, vibration-resistant clamping with excellent access to all five faces of the part — perfect for 5-axis machining.

• Rigid & Repeatable:
  Precision ground surfaces and hardened steel body deliver ultra-tight repeatability (≤ 0.005 mm) and exceptional holding power.

• Time-Saving Setup:
  Reduces need for soft jaws or custom fixtures. Simply prep your raw stock with a matching dovetail and you're ready to cut.

• Made for Pro Shops:
  Ideal for aerospace, medical, prototyping, and high-tolerance parts where setup speed and holding integrity matter.

Technical Specifications:

• Diameter: 97 mm

• Height: 84 mm

• Clamping Type: Dovetail

• Stud Interface: Integrated 52 mm zero-point stud

• Material: Hardened tool steel (≥ 56 HRC)

• Surface Finish: Ground

• Repeatability: ≤ 0.005 mm

• Applications: 3- and 5-axis machining, prototyping, small-part runs, precision milling

The Full Grip – Mini Dovetail Clamp brings together compact design, unbeatable access, and zero-point speed — making it a must-have tool for advanced machining setups that demand precision without compromise.

DIMENSIONS:

52 Stud | 97D × 84 mm
