The Full Grip - Self Centering Vice - 77 x 170 - Removable Jaws

The Full Grip – Self Centering Vice

77 x 170 mm | Removable Jaws
Slimline Centering Vice for Precision Workholding in Tight Spaces

The Full Grip – Self Centering Vice – 77 x 170 offers an ideal balance of compact design and extended clamping capacity, making it perfect for small-to-mid sized components that require true centerline positioning and fast setup times. With a 77 mm jaw width and up to 170 mm of clamping range, this vice is built for tight setups, multi-vice configurations, and 5-axis machining where every millimeter of clearance counts.

Its removable jaw system allows quick adaptation to different parts and materials, supporting hardened jaws, soft jaws, or custom profiles — all while delivering consistent precision and rigid clamping.

Key Features:

• Extended Clamping in a Compact Body:
  170 mm of clamping range in a small footprint, ideal for flexible fixture arrangements on small machines or tombstones.

• Self-Centering Mechanism:
  Both jaws move symmetrically to clamp parts on true centerline — simplifying programming and ensuring perfect balance.

• Removable & Interchangeable Jaws:
  Standard hardened steel jaws included; compatible with custom or soft jaw inserts for delicate or complex parts.

• High Precision Construction:
  Hardened steel body and precision-ground surfaces ensure repeatability of ≤ 0.01 mm and excellent vibration damping.

• Low-Profile, 5-Axis Friendly:
  Slim vertical height allows excellent tool access from all angles, making it ideal for 5-axis milling.

• Zero-Point System Compatible:
  Mounts via bolt pattern or optional zero-point pull studs for fast changeovers in modular setups.

Technical Specifications:

• Clamping Range: 0–170 mm

• Jaw Width: 77 mm

• Jaw Type: Removable / quick-change

• Material: Hardened tool steel (≥ 56 HRC)

• Surface Finish: Ground

• Repeatability: ≤ 0.01 mm

• Mounting Options: Bolt-down and zero-point adaptable

• Best For: Small part machining, 5-axis setups, modular fixture systems, high-precision prototyping

DIMENSIONS

170 x 77 x 60. 7mm
